3.6mm Self-locking Nylon Cable Tie
Basic Data
Material: Polyamide 6.6 (PA66)
Flammability: UL94 V2
Properties: Acid resistance, corrosion resistance, good insulation, not easy to age, strong endurance.
product category:Internal tooth tie
Is it reuasable: no
Installation temperature: -10℃~85℃
Working Temperature: -30℃~85℃
Color: The standard color is natural(white) color, which is suitable for indoor usage;
Shiyun Black color cable tie are manufactured with special additives imparting resistant to UV radiation that prolongs the life of cable ties, it is suitable for outdoor usage.
SPECIFICATION
|
Item No. |
Width(mm) |
Length |
Thickness |
Bundle Dia.(mm) |
Min.loopTensile Strength |
SHIYUN# Tensile Strength |
|||
|
INCH |
mm |
mm |
LBS |
KGS |
LBS |
KGS |
|||
|
SY1-1-32120 |
3.2 |
4 3/4″ |
120 |
1.05 |
3-30 |
40 |
18 |
47 |
21 |
|
SY1-1-32150 |
6″ |
150 |
1.05 |
3-35 |
40 |
18 |
47 |
21 |
|
|
SY1-1-36140 |
3.6 |
5 1/2″ |
140 |
1.2 |
3-33 |
40 |
18 |
55 |
25 |
|
SY1-1-36150 |
6″ |
150 |
1.2 |
3-35 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36180 |
7″ |
180 |
1.2 |
3-42 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36200 |
8″ |
200 |
1.2 |
3-50 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36250 |
10″ |
250 |
1.25 |
3-65 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36280 |
11″ |
280 |
1.25 |
3-70 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36300 |
11 5/8″ |
300 |
1.3 |
3-80 |
40 |
18 |
55 |
25 |
|
|
SY1-1-36370 |
14 3/5″ |
370 |
1.35 |
3-105 |
40 |
18 |
55 |
25 |
|
Function Explanation
These cable ties are appropriate for intermediate duty bundling applications not to exceed 40 lbs. of bundling force.
Advantages
1. Nylon straps can assist wire storage, effectively saving space and solving the problem of messy wires
2. In addition to power cord storage, cable ties are also suitable for wire management of all peripheral devices of 3C products
3. The cable tie has high toughness, wear resistance and pressure resistance to protect the wire
4. High-quality cable ties, strong tension and not easy to break
5. The cable harness has a simple self-locking design, which can be locked once pulled, suitable for bundling and organizing various wires and cables
6. Cable ties are widely used in household, workplace, public places, etc.
